Schneider Electric LC1K1201G7 TeSys K Mini Contactor
5.0 Rating
Model Ref: LC1K1201G7
Product Overview
TeSys K compact mini contactor for motor control (AC-3) up to 12A at 440V and resistive loads (AC-1). Features 3 poles (3P), 120V AC coil, 1 NC auxiliary contact, and screw clamp terminals. Compact size with improved fire resistance (IEC 60335-1) and anti-flammable refrigerant certification (IEC 60335-2-40). Ideal for simple control systems and space-constrained installations.
Key Features & Value
- Genuine Schneider Electric Part
- Tested for High Reliability
- Compact design, easy integration
- Global safety certifications
Price on Request
Contact Us
* Available for quotation upon request
Technical Specifications
Detailed parameters for model LC1K1201G7
| Parameter | Specification Details |
|---|---|
| Poles | 3P (3 NO) |
| Rated Operational Current | 12 A (<= 440 V AC AC-3) |
| Coil Voltage | 120 V AC 50/60 Hz |
| Auxiliary Contacts | 1 NC |
| Connection Type | Screw Clamp Terminals |
| Mounting Support | Plate, Rail |
